Product name:QD series gas spring
QD series gas spring
QD series of air springs are widely used in the promotion of components, support, the balance of gravity and replace the sophisticated mechanical spring, etc.. The use of oil circuit to control the latest structure of gas displacement production, with a rising buffer, light in place of the excellent features. QD series of air spring with high pressure inert gas as the driving force in the working process of supporting force is constant, which is the biggest characteristic is superior to the ordinary gas spring, and has advantages of convenient installation, safe usage and free maintenance etc..
QD系列气弹簧现有(部分)规格一览表
QD13 100N≈10Kgf
代号 | L | S | Kgf(N×10) | 接头形式 |
01 | 110 | 30 | 2、57、10 | AA、CC、AC |
02 | 150 | 50 | 5、10、15 | AA、AC |
03 | 180 | 75 | 5、10、20 | EF、FF |
04 | 210 | 85 | 5、10、15、20 | AA |
05 | 250 | 90 | 5、10、20 | AF、CC |
06 | 300 | 110 | 5、10、20、25 | AA、FF |
07 | 340 | 120 | 5、10、20、25 | CC、AA |
08 | 360 | 140 | 5、10、15、30 | AA、CC、AC |
09 | 380 | 140 | 5、15、25 | AA、CC、AC |
QD16
代号 | L | S | Kgf(N×10) | 接头形式 |
01 | 190 | 40 | 5 | AA |
02 | 210 | 50 | 30 | AA/DD |
03 | 250 | 70 | 10、20、25、30 | AA/AD |
04 | 300 | 100 | 40 | AA/DA |
05 | 340 | 110 | 45 | AA |
06 | 400 | 130 | 40 | DD |
07 | 480 | 180 | 45 | DD |
08 | 500 | 190 | 30 | AA |
09 | 580 | 220 | 50 | DD |
10 | 600 | 250 | 40 | AA |
代号 L S Kgf(N×10) 接头形式 01 250 50 50 AB/BB 02 300 100 60 BB 03 340 100 70 BB 04 380 120 50 EF 05 420 130 55 AE 06 450 150 55 FF 07 480 160 75 GG/DD 08 605 200 55 BD 09 680 280 70 BD/DD 10 700 300 40 CC 代号 L S Kgf(N×10) 接头形式 01 735 220 90 CC 02 775 240 120 GG 03 780 280 130 GG 04 900 300 120 AA 05 1000 350 90 CA 06 1100 350 90 AF Description: a part of the above specifications only thousands of specifications, only need to provide the maximum installation (center distance), stroke, and lift joint form can be separately designed, or sample order, not the other charges, combined joint form is not restricted; QD10 series for small size without gas spring. List, can be produced according to customer requirements.
QD25
